Eaton SmartWire-DT SWD Series User Manual

13 Appendix
13.7 Technical data
284 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
13.7.11 NZM circuit-breakers-...
NZM-XSWD-704
General
Standards IEC/EN 61131-2; EN 50178
Dimensions W x H x D mm
35 x 90 x 101
Weight kg
0.1
Mounting
DIN-rail IEC/EN 60715, 35 mm
Mounting position
vertical
Ambient mechanical conditions
Degree of protection (IEC/EN 60529,
EN50178, VBG 4)
IP20
Vibrations
(IEC/EN 61131-2:2008)
Constant amplitude 3.5 mm Hz 5 - 8.4
Constant acceleration, 1 g Hz
8.4 - 150
Mechanical shock resistance (IEC/EN 60068-
2-27)
semi-sinusoidal 15 g/11 ms
Impact
resis-
tances
9
Drop to IEC/EN 60068-2-31 Drop
height
mm
50
Free fall, packaged
(IEC/EN 60068-2-32)
m
0.3
Electromagnetic compatibility (EMC)
Overvoltage category II
pollution degree
2
Electrostatic discharge
(IEC/EN 61131-2:2008)
Air discharge (Level 3) kV 8
Contact discharge (Level 2) kV
4
Electromagnetic fields (IEC/EN 61131-
2:2008)
80-1000 MHz V/m 10
1.4 - 2 GHz V/m
3
2 - 2.7 GHz V/m
1
Radio interference suppression (SmartWire-
DT)
EN 55011 Class A
Burst (IEC/EN 61131-2:2008, Level 3)
Supply cables kV 2
Signal cables kV
1
SmartWire-DT cables kV
1
Surge (IEC/EN 61131-2:2008, Level 1)
–
Radiated RFI
(IEC/EN 61131-2:2008, Level 3)
V
10
Ambient climatic conditions
Operating ambient temperature
(IEC 60068-2)
°C –25 - +55
Condensation
Must be prevented with suitable measures
Storage °C
–40 - +70
Relative humidity, non-condensing (IEC/EN
60068-2-30)
%
5 - 95
SmartWire-DT interface
Module type SmartWire-DT module (slave)
Baud rate setting
Automatic
Status SmartWire-DT LED
Green
