Eaton SmartWire-DT SWD Series User Manual

0 About this manual
0.1 List of revisions
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 9
0 About this manual
0.1 List of revisions
The following significant changes have been made in comparison to previous
issues (1st edition from 02/2009):
Publica-
tion date
Page Keyword New Modifi-
cation
07/2013 203 Chapter “SL4-SWD and SL7-SWD base modules for
signal towers”
✓
253 EU5E-SWD-4PT-2 added to ￫ Section “2.14 Analog
modules EU5E-SWD-4PT and EU5E-SWD-4PT-2”, page
59
✓
253 „SL4-SWD“, „SL7-SWD“, „EU5E-SWD-4PT-2“ added to
table „Maximum current consumption of SmartWire-DT
modules on USWD“
✓
255 „SL4-SWD“, „SL7-SWD“, „EU5E-SWD-4PT-2“added to
„Data requirement (bytes) SmartWire-DT modules“
✓
268 „SL4-SWD“, „SL7-SWD“, „EU5E-SWD-4PT-2“added to
table Table13.7.3, „I/O modules, analog“
✓
275 Chapter “M22-SWD connections” ✓
11/2013 139 Chapter “PKE-SWD-CP, Connection for circuit-breaker
PKE”
✓
153 Chapter 7 „Electronic motor starter EMS-…-SWD-ADP“ ✓
04/2014 213 Chapter “Interface module MCB-HK-SWD for circuit-
breakers and residual current circuit-breakers”
✓
05/2015 21 Corrections in Chapter “I/O modules EU5E-SWD…” ✓
155 Chapter “Pilot devices M22-SWD…” restructured ✓
159 Chapter “Potentiometers M22-SWD-R” ✓
160 Chapter “Encoders M22-SWD-INC” ✓
08/2015 51.56 EU5E-SWD-4PT-2, temperature corrected ✓
04/2017 147, 149 Trip reasons changed in
Section “Outputs” and Section “Differential trip indica-
tion (TRIPR)”
✓
149 Measuring accuracy changed in Section “Relative
current value (I-REL)”
✓
34 "EU5E-SWD-4D4D-R module ✓✓
09/2017 34 ff. Module "EU5E-SWD-4D4D-R" corrected ✓
12/2017 155 ff. Dimmable LED ✓
– Chapter 7 „Electronic motor starter EMS-…-SWD-ADP“
replaced with "EMS-…-SWD, Electronic Motor Starter",
MN034002ZU
✓
