Eaton SmartWire-DT SWD Series User Manual

13 Appendix
13.7 Technical data
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 279
13.7.8 Enclosure bushings: plug, socket
SWD4-SF8-20 SWD4-SM8-20
General
Standards IEC/EN 61131-2
EN 50178_x
IEC/EN 61131-2
EN 50178_x
Dimensions W x H x D mm
24 x 26 x 162 24 x 26 x 170
Weight g
20 22.5
Mounting position
Any Any
Ambient mechanical conditions
Degree of protection (IEC/EN 60529, EN50178, VBG 4) IP67 IP67
Ambient climatic conditions
Operating ambient temperature (IEC 60068-2) °C -25 - +55 -25 - +55
Condensation
Must be prevented with suitable measures
Storage °C
-40 - +70 -40 - +70
Relative humidity, non-condensing
(IEC/EN 60068-2-30)
%
5 - 95 5 - 95
Connection options
SWD In – Plug, 8-pole
Number of insertion cycles
–  500
SWD Out
Socket, 8-pole –
Number of insertion cycles
 500 –
Current consumption (15-V-SmartWire-DT supply)
￫ Page 253
