Eaton SmartWire-DT SWD Series User Manual

6 PKE-SWD-CP, Connection for circuit-breaker PKE
6.10 Programming
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 153
6.10.3 Acyclic data PKE-SWD-CP
The following acyclical objects can be read via the PKE-SWD-CP in addition
to the cyclical input and output bytes.
The required object is addressed with parameters “ID” and “Index”. The
input address of the SmartWire-DT module with which communication is to
be established is set with parameter “ID”. Meanwhile, the "Index" parameter
specifies the address of the actual object. The first object is assigned num-
ber 1, the second number 2 etc. For the PKE-SWD-CP, object 1 supplies cur-
rent value “I-REL-MAX”.
Object 1 [Index 1]:
Byte 0:
Object 2 [Index 2]:
Byte 0:
Object 3 [Index 3]:
Byte 0:
76543210
I-REL-MAX I-REL-MAX I-REL-MAX I-REL-MAX I-REL-MAX I-REL-MAX I-REL-MAX I-REL-MAX
Data byte
Data bit Designation Description Notes
0 0-7 I-REL-MAX Relative current
value of the highest
phase current [%]
￫ Section
6.10.1.6, „Relative current
value (I-REL)“, page 149
76543210
TH TH TH TH TH TH TH TH
Data byte
Data bit Designation Description Notes
0 0-7 TH Thermal motor
image [%]
￫ Section
6.10.1.7, „Thermal model
(TH)“, page 150
76543210
– – I>I>I>TYPETYPETYPE
Data byte Data bit Designation Description Notes
0 0-2 TYPE Control option part
no.
￫ Section 6.10.1.8, „Type
of trip block (TYPE)“, page
150
3-5 I> Factor for short-
circuit current
￫ Section
6.10.1.9, „Short-circuit
release (I >) factor“, page
151
6-7 Not used – –
