Eaton SmartWire-DT SWD Series User Manual

13 Appendix
13.7 Technical data
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 265
13.7.2 I/O modules, digital
EU5E-SWD-8DX EU5E-SWD-4DX EU5E-SWD-4D2R EU5E-SWD-4D4D/
EU5E-...-4D4D-R
EU5E-X8D
General
Standards IEC/EN 61131-2, EN 50178
Dimensions W x H x D mm 35 x 90 x 101 35 x 90 x 101 35 x 90 x 101 35 x 90 x 101 35 x 90 x 101
Weight kg
0.1 0.1 0.1 0.1 0.1
Mounting
DIN-rail IEC/EN 60715, 35 mm
Mounting position
vertical
Ambient mechanical conditions
Degree of protection (IEC/EN
60529,
EN50178, VBG 4)
IP20 IP20 IP20 IP20 IP20
Vibrations (IEC/EN 61131-2:2008)
Constant ampli-
tude 3.5 mm
Hz 5 - 8.4 5 - 8.4 5 - 8.4 5 - 8.4 5 - 8.4
Constant accelera-
tion, 1 g
Hz
8.4 - 150 8.4 - 150 8.4 - 150 8.4 - 150 8.4 - 150
Mechanical shock
resistance (IEC/EN
60068-2-27)
semi-sinusoidal 15 g/
11 ms
Impact
resis-
tances
9 9 9 9 9
Drop to IEC/EN 60068-
2-31
Drop
height
50mm 50 50 50 50
Free fall, packaged
(IEC/EN 60068-2-32)
m
0.3 0.3 0.3 0.3 0.3
Electromagnetic compatibility (EMC)
Overvoltage category
II II II II II
pollution degree
2 2 2 2 2
Electrostatic discharge (IEC/EN 61131-2:2008)
Air discharge
(Level 3)
kV
8 8 8 8 8
Contact discharge
(Level 2)
kV
4 4 4 4 4
Electromagnetic fields (IEC/EN 61131-2:2008)
80 - 1000 MHz V/m
10 10 10 10 10
1.4 - 2 GHz V/m
3 3 3 3 3
2 - 2.7 GHz V/m
1 1 1 1 1
Radio interference suppression
(SmartWire-DT) EN55011
Class A Class A Class A Class A Class A
Burst (IEC/EN 61131-2:2008, Level 3)
Supply cables 2kV 2kV 2kV 2kV 2kV
Signal cables
1kV 1kV 1kV 1kV 1kV
SmartWire-DT cables
1kV 1kV 1kV 1kV 1kV
Surge (IEC/EN 61131-2:2008, Level
1)
– Supply cables 0.5 kV – Supply cables 0.5 kV Supply cables 0.5 kV
