Eaton SmartWire-DT SWD Series User Manual

11 Interface for NZM compact circuit-breakers
11.2 Surface mounting
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 229
11.2.1 Indication and connection elements
The network status of the module is signalled via the SmartWire-DT diagnos-
tics LED.
The other LEDs have the following function:
11.2.2 Porting
The module does not require an auxiliary power supply, it is supplied com-
pletely via the SmartWire-DT connecting cable.
C on Communication with the circuit-breaker via data cable active
off No communication with the circuit-breaker
2x-
Without function
S
For indicating the S0 energy pulses
on A momentary off state indicates an energy pulse.
off No power supply via SmartWire-DT
flashing / ~ 1 Hz Power meters invalid
I0
on Voltage at I0
off No voltage at I0
I01
on Voltage at I1
off No voltage at I1
Q0
on Output Q0 is on
off Output Q0 is off
Q1
on Output Q1 is on
off Output Q1 is off
￫
The voltage state of the inputs is indicated:
￫
The voltage state of the outputs is indicated:
I0 Led 0 1 0 1
I1 Led
0 0 1 1
Circuit-breaker status
- off Trip on
Q0 Led 0 1 0 1
Q1 Led
0 0 1 1
Attribute ID
- OFF ON -
