Menu 7
Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance RFC mode
154 Unidrive SP Advanced User Guide
www.controltechniques.com Issue Number: 10
The thresholds are given in the table below in °C :
This value can be used to trim out any offset from the user input signal
Drive size Fan threshold Lower fan threshold Upper fan threshold
SP0xxx N/A N/A N/A
SP1xxx 60 N/A N/A
SP2xxx 60 N/A N/A
SP3xxx N/A 55 70
SP4xxx N/A 55 62
SP5xxx N/A 55 62
SP6xxx N/A 55 65
SPMAxxxx N/A 55 65
SPMDxxxx N/A 55 65
7.07 T5/6 analog input 1 offset trim
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
311
Range
Open-loop, Closed-loop vector, Servo,
Regen
±10.000 %
Default
Open-loop, Closed-loop vector, Servo,
Regen
0.000
Update rate Background read
7.08 T5/6 analog input 1 scaling
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
3111
Range
Open-loop, Closed-loop vector, Servo,
Regen
0.000 to 4.000
Default
Open-loop, Closed-loop vector, Servo,
Regen
1.000
Update rate Background read
7.09 T5/6 analog input 1 invert
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default
Open-loop, Closed-loop vector, Servo,
Regen
0
Update rate Background read
7.10 T5/6 analog input 1 destination
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 2 1111
Range
Open-loop, Closed-loop vector, Servo,
Regen
Pr 0.00 to Pr 21.51
Default
Open-loop, Closed-loop vector, Servo
Regen
Pr 1.36
Pr 0.00
Update rate Read on drive reset
