5.13 Menu 11: General drive set-up
These parameters define the parameters that reside in the programmable area in menu 0.
Table 5-12 Default settings:
11.01 Parameter 0.11 set-up
11.02 Parameter 0.12 set-up
11.03 Parameter 0.13 set-up
11.04 Parameter 0.14 set-up
11.05 Parameter 0.15 set-up
11.06 Parameter 0.16 set-up
11.07 Parameter 0.17 set-up
11.08 Parameter 0.18 set-up
11.09 Parameter 0.19 set-up
11.10 Parameter 0.20 set-up
11.11 Parameter 0.21 set-up
11.12 Parameter 0.22 set-up
11.13 Parameter 0.23 set-up
11.14 Parameter 0.24 set-up
11.15 Parameter 0.25 set-up
11.16 Parameter 0.26 set-up
11.17 Parameter 0.27 set-up
11.18 Parameter 0.28 set-up
11.19 Parameter 0.29 set-up
11.20 Parameter 0.30 set-up
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
2 1111
Range
Open-loop, Closed-loop vector, Servo,
Regen
Pr 1.00 to Pr 21.51
Default
Open-loop, Closed-loop vector, Servo,
Regen
See Table 5-12
Update rate Background read
Parameter Menu 0 Open-loop Closed-loop vector Servo Regen
Pr 11.01 Pr 0.11 Pr 5.01 Pr 5.01 Pr 3.29 Pr 5.01
Pr 11.02 Pr 0.12 Pr 4.01 Pr 4.01 Pr 4.01 Pr 4.01
Pr 11.03 Pr 0.13 Pr 4.02 Pr 4.02 Pr 7.07 Pr 4.02
Pr 11.04 Pr 0.14 Pr 4.11 Pr 4.11 Pr 4.11 Pr 5.03
Pr 11.05 Pr 0.15 Pr 2.04 Pr 2.04 Pr 2.04 Pr 3.01
Pr 11.06 Pr 0.16 Pr 8.39 Pr 2.02 Pr 2.02 Pr 3.02
Pr 11.07 Pr 0.17 Pr 8.26 Pr 4.12
Pr 4.12 Pr 4.08
Pr 11.08 Pr 0.18 Pr 8.29 Pr 8.29 Pr 8.29 Pr 8.29
Pr 11.09 Pr 0.19 Pr 7.11 Pr 7.11 Pr 7.11 Pr 7.11
Pr 11.10 Pr 0.20 Pr 7.14 Pr 7.14 Pr 7.14 Pr 7.14
Pr 11.11 Pr 0.21 Pr 7.15 Pr 7.15 Pr 7.15 Pr 7.15
Pr 11.12 Pr 0.22 Pr 1.10 Pr 1.10 Pr 1.10 Pr 0.00
Pr 11.13 Pr 0.23 Pr 1.05 Pr 1.05 Pr 1.05 Pr 0.00
Pr 11.14 Pr 0.24 Pr 1.21 Pr 1.21 Pr 1.21 Pr 0.00
Pr 11.15 Pr 0.25 Pr 1.22 Pr 1.22 Pr 1.22 Pr 0.00
Pr
11.16 Pr 0.26 Pr 1.23 Pr 3.08 Pr 3.08 Pr 0.00
Pr 11.17 Pr 0.27 Pr 1.24 Pr 3.34 Pr 3.34 Pr 0.00
Pr 11.18 Pr 0.28 Pr 6.13 Pr 6.13 Pr 6.13 Pr 0.00
Pr 11.19 Pr 0.29 Pr 11.36 Pr 11.36 Pr 11.36 Pr 11.36
Pr 11.20 Pr 0.30 Pr 11.42 Pr 11.42 Pr 11.42 Pr 11.42
