Menu 7
Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance RFC mode
156 Unidrive SP Advanced User Guide
www.controltechniques.com Issue Number: 10
The following modes are available for the analog input 3. In modes 2 & 3 a current loop loss trip is generated if the input current falls below 3mA.
In modes 2 and 4 the destination parameter is at a value equivalent to 0.0% when the input current is less than 4mA. In modes 3 and 5 the destination
parameter is at a value equivalent to 100.0% when the input current is less than 4mA.
7.15 T8 analog input 3 mode
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range
Open-loop, Closed-loop vector, Servo,
Regen
0 to 9
Default
Open-loop, Closed-loop vector, Servo
Regen
8
6
Update rate Background read
Parameter value Parameter string Mode Comments
0 0-20 0 - 20mA
1 20-0 20 - 0mA
2 4-20.tr 4 -20mA with trip on loss Trip if I < 3mA, Pr 7.03 = 0.0% if I < 4mA
3 20-4.tr 20 - 4mA with trip on loss Trip if I < 3mA, Pr 7.03 = 100.0% if I < 4mA
4 4-20 4 - 20mA with no trip on loss Pr 7.03 = 0.0% if I < 4mA
5 20-4 20 - 4mA with no trip on loss Pr 7.03 = 100.0% if I < 4mA
6 VOLt Voltage mode
7 th.SC Thermistor with short circuit detection
TH trip if R > 3k3
TH reset if R < 1k8
THS trip if R < 50R
8 th Thermistor without short circuit detection
TH trip if R > 3k3
TH reset if R < 1k8
9 th.diSp Thermistor display only with no trip
7.16 T8 analog input 3 scaling
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
3 111
Range
Open-loop, Closed-loop vector, Servo,
Regen
0.000 to 4.000
Default
Open-loop, Closed-loop vector, Servo,
Regen
1.000
Update rate Background read
7.17 T8 analog input 3 invert
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default
Open-loop, Closed-loop vector, Servo,
Regen
0
Update rate Background read
7.18 T8 analog input 3 destination
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 2 1111
Range
Open-loop, Closed-loop vector, Servo,
Regen
Pr 0.00 to Pr 21.51
Default
Open-loop, Closed-loop vector, Servo,
Regen
Pr 0.00
Update rate Read on drive reset
