Emerson unidrive sp User Manual

Menu 3
Closed-loop
Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance RFC mode
60 Unidrive SP Advanced User Guide
www.controltechniques.com Issue Number: 10
If the speed feedback (Pr 3.02) exceeds this level in either direction an overspeed trip is produced. If this parameter is set to zero the overspeed
threshold is automatically set to 1.2 x SPEED_FREQ_MAX.
In servo mode the motor speed and the motor voltage can be monitored to detect that the motor is accelerating in an uncontrolled way because the
motor phasing angle has not been set up correctly in Pr 3.25 (Pr 21.20 if motor map 2 is selected). If the overspeed threshold is set to zero phasing
angle error monitoring is enabled. If the overspeed threshold is set to any other value this feature is disabled.
See Pr 3.06 and Pr 3.07 on page 59.
3.08 Overspeed threshold
Drive modes Closed-loop vector, Servo
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range Closed-loop vector, Servo 0 to 40,0000 rpm
Default Closed-loop vector, Servo 0
Update rate Background read
3.09 Absolute “at speed” detect
Drive modes Open-loop, Closed-loop vector, Servo
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default Closed-loop vector, Servo 0
Update rate Background read
3.10
Speed controller proportional gain (Kp1)
3.13
Speed controller proportional gain (Kp2)
Drive modes Closed-loop vector, Servo
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
4 111
Range Closed-loop vector, Servo
0.0000 to 6.5535 (1/ rad s
-1
)
Default
Closed-loop vector
Servo
0.0300
0.0100
Second motor
parameter
Closed-loop vector, Servo Pr 21.17
Update rate Background read
3.11
Speed controller integral gain (Ki1)
3.14
Speed controller integral gain (Ki2)
Drive modes Closed-loop vector, Servo
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
2 111
Range Closed-loop vector, Servo
0.00 to 655.35 s/rad s
-1
Default
Closed-loop vector
Servo
0.10
1.00
Second motor
parameter
Closed-loop vector, Servo Pr 21.18
Update rate Background read
