Emerson unidrive sp User Manual

Menus 15 to 17
SM-Resolver
Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance RFC mode
276 Unidrive SP Advanced User Guide
www.controltechniques.com Issue Number: 10
The excitation level can be controlled for use with 3:1 ratio resolvers (Pr x.13 = 0), or 2:1 ratio resolvers (Pr x.13 = 1 or 2).
Resolvers with the following numbers of poles can be used with the Solutions Module.
0: 2POLE
1: 4POLE
2: 6POLE
3 to 12: 8POLE
A 2 pole resolver can be selected as drive speed feedback with a motor with any number of poles. A resolver with a number of poles greater than 2
can only be used with a motor where the number of revolver poles divides exactly into the number of motor poles i.e. a 4 pole resolver with an 8 pole
motor.
Trips can be enabled/disabled using Pr x.17 as follows:
The binary sum defines the level of error detection as below:
The wire break trip is not activated provided one signal is >1.5Vrms or both are >0.2Vrms approximately.
x.13 Resolver excitation
RW Uni US
Ú
3:1 (0), 2:1 (1 or 2)
Ö
3:1 (0)
Update rate: Background read
x.15 Resolver poles
RW Uni US
Ú
2POLE (0), 4POLE (1),
6POLE (2), 8POLE (3 to
12)
Ö
2POLE (0)
Update rate: Background read
x.17 Error detection level
RW Uni US
Ú
0 to 7
Ö
1
Update rate: Background read
Bit Function
0 Wire break detect
1 Not used
2 Not used
Bit 2 Bit 1 Bit 0 Error detection level Value in Pr x.17
0 0 0 Error detection disabled 0
0 0 1 Wire break detect 1
0 1 0 Error detection disabled 2
0 1 1 Wire break detect 3
1 0 0 Error detection disabled 4
1 0 1 Wire break detect 5
1 1 0 Error detection disabled 6
1 1 1 Wire break detect 7
NOTE
