Emerson unidrive sp User Manual

Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance RFC mode
Menu 7
Unidrive SP Advanced User Guide 155
Issue Number: 10 www.controltechniques.com
The following modes are available for the analog input 2. In modes 2 & 3 a current loop loss trip is generated if the input current falls below 3mA.
In modes 2 and 4 the destination parameter is at a value equivalent to 0.0% when the input current is less than 4mA. In modes 3 and 5 the destination
parameter is at a value equivalent to 100.0% when the input current is less than 4mA.
7.11 T7 analog input 2 mode
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 111
Range
Open-loop, Closed-loop vector, Servo,
Regen
0 to 6
Default
Open-loop, Closed-loop vector, Servo,
Regen
6
Update rate Background read
Parameter
value
Parameter
string
Mode Comments
00-20 0 - 20mA
1 20-0 20 - 0mA
2 4-20.tr 4 -20mA with trip on loss Trip if I < 3mA, Pr 7.02 = 0.0% if I < 4mA
3 20-4.tr 20 - 4mA with trip on loss Trip if I < 3mA, Pr 7.02 = 100.0% if I < 4mA
4 4-20 4 - 20mA with no trip on loss Pr 7.02 = 0.0% if I < 4mA
5 20-4 20 - 4mA with no trip on loss Pr 7.02 = 100.0% if I < 4mA
6 VOLt Voltage mode
7.12 T7 analog input 2 scaling
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
3 111
Range
Open-loop, Closed-loop vector, Servo,
Regen
0.000 to 4.000
Default
Open-loop, Closed-loop vector, Servo,
Regen
1.000
Update rate Background read
7.13 T7 analog input 2 invert
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default
Open-loop, Closed-loop vector, Servo,
Regen
0
Update rate Background read
7.14 T7 analog input 2 destination
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 2 1111
Range
Open-loop, Closed-loop vector, Servo,
Regen
Pr 0.00 to Pr 21.51
Default
Open-loop, Closed-loop vector, Servo
Regen
Pr 1.37
Pr 3.10
Update rate Read on drive reset
