Emerson unidrive sp User Manual

Menu 7
Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance RFC mode
158 Unidrive SP Advanced User Guide
www.controltechniques.com Issue Number: 10
The following modes are available for the analog outputs.
In voltage mode the output range is -10V to 10V. If the scaling parameter is 1.000 then -10V and 10V are produced when the source parameter is at -
maximum and maximum respectively. Different scaling can be applied with Pr 7.23. If the result of the scaling produces an output of more than +/-
100% the output is clamped within the +/-10V range.
In current modes with a scaling parameter of 1.000 the minimum and maximum current are produced when the source parameter is at 0 and
maximum respectively. Therefore in 4 - 20mA mode the output is 4mA when the source parameter is zero. Different scaling can be applied with
Pr 7.23. If the result of the scaling produces an output of more than 100% the output is clamped at 20mA.
If high speed update mode is selected and the source for the output is one of the parameters designated for high speed analog output operation (see
start of this section) the output is updated at a higher rate with special scaling. If the parameter selected is not designated for this mode the output is
updated at the normal rate. If speed feedback or power is selected for high speed mode for both analog output 1 and analog output 2 the setting is
ignored for analog output 2. If the high speed mode is selected the output is always a voltage signal.
7.22 T10 analog output 2 source
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
2 1111
Range
Open-loop, Closed-loop vector, Servo,
Regen
Pr 0.00 to Pr 21.51
Default
Open-loop, Closed-loop vector, Servo
Regen
Pr 4.02
Pr 5.05
Update rate Read on drive reset
7.23 T10 analog output 2 scaling
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
3 111
Range
Open-loop, Closed-loop vector, Servo,
Regen
0.000 to 4.000
Default
Open-loop, Closed-loop vector, Servo,
Regen
1.000
Update rate Background read
7.24 T10 analog output 2 mode
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range
Open-loop, Closed-loop vector, Servo,
Regen
0 to 3
Default
Open-loop, Closed-loop vector, Servo,
Regen
0
Update rate Background read
Parameter value Parameter string Mode
0 VOLt Voltage mode
10-20 0 - 20mA
24-20 4 - 20mA
3 H.SPd High speed update mode
