Emerson unidrive sp User Manual

Menu 10
Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance RFC mode
202 Unidrive SP Advanced User Guide
www.controltechniques.com Issue Number: 10
This parameter gives an indication of braking resistor temperature based on a simple thermal model, see Pr 10.30 and Pr 10.31 on page 198. Zero
indicates the resistor is close to ambient and 100% is the maximum temperature (trip level). A br.rS warning is given if this parameter is above 75%
and the braking IGBT active.
The bits in this parameter correspond to the status bits in menu 10 as follows.
10.39 Braking energy overload accumulator
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 1 1 1
Range
Open-loop, Closed-loop vector, Servo,
Regen
0.0 to 100.0 %
Update rate Background read
10.40 Status word
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111 1
Range
Open-loop, Closed-loop vector, Servo,
Regen
0 to 32,767
Update rate Background write
15 14 13 12 11 10 9 8
Not used Pr 10.15 Pr 10.14 Pr 10.13 Pr 10.12 Pr 10.11 Pr 10.10 Pr 10.09
76543210
Pr 10.08 Pr 10.07 Pr 10.06 Pr 10.05 Pr 10.04 Pr 10.03 Pr 10.02 Pr 10.01
10.41 Trip 0 time: years.days
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
31 1 1 11
Range
Open-loop, Closed-loop vector, Servo,
Regen
0.000 to 9.364 Years.Days
Update rate Background write
10.42 Module number for trip 0, or Trip 0 time: hours.minutes
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1211111
Range
Open-loop, Closed-loop vector, Servo,
Regen
00.00 to 23.59 Hours.Minutes
Update rate Background write
