Emerson unidrive sp User Manual

Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance RFC mode
Menu 11
Unidrive SP Advanced User Guide 213
Issue Number: 10 www.controltechniques.com
Gives the type/mode of the data block selected with Pr 11.37 as shown below.
Gives the version number of the data block. This is intended to be used when data blocks are used as drive macros. If a version number is to be
stored with a data block this parameter should be set to the required version number before the data is transferred. Each time Pr 11.37 is changed by
the user the drive puts the version number of the currently viewed data block in this parameter.
Gives the checksum of the data block, space left on the card, the total space on the card for the card flags see Pr 11.37 for details.
Sets the timeout for the drive display to revert to status mode from edit mode following no key presses. Although this parameter can be set to less
than 2s, the minimum timeout is 2s.
Pr 11.38 String Type/mode
0 FrEE Value when Pr 11.37 = 0
1 3C.SE Commander SE mode parameter file (not used)
2 3OPEn.LP Open-loop mode parameter file
3 3CL.VECt Closed-loop vector mode parameter file
4 3SErVO Servo mode parameter file
5 3REGEn Regen mode parameter file
6-8 3Un Unused
9 4C.SE Commander SE mode difference from default file (not used)
10 4OPEn.LP Open-loop mode difference from default file
11 4CL.VECt Closed-loop vector mode difference from default file
12 4SErVO Servo mode difference from default file
13 4REGEn Regen mode difference from default file
14-16 4Un Unused
17 LAddEr Onboard Application Lite user program file
18 Option
A file containing user defined data (normally created by an SM-
Applications Solutions Module)
11.39 SMARTCARD data version
Drive modes Open-loop, Closed-loop, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range Open-loop, Closed-loop, Servo, Regen 0 to 9,999
Default Open-loop, Closed-loop, Servo, Regen 0
Update rate Background read/write
11.40 SMARTCARD data checksum
Drive modes Open-loop, Closed-loop, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111 1
Range Open-loop, Closed-loop, Servo, Regen 0 to 65,335
Update rate Background write
11.41 Status mode time-out
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range
Open-loop, Closed-loop vector, Servo,
Regen
0 to 250 s
Default
Open-loop, Closed-loop vector, Servo,
Regen
240
Update rate Background read
