Table 6-11 Parameter set-up to reproduce Macro 5 on a Unidrive SP
Parameter
Value
OL CL
7.10 Analog input 1 destination Pr 0.00
7.14 Analog input 2 destination Pr 1.27
7.15 Analog input 3 mode Volt (6)
7.18 Analog input 3 destination Pr 1.28
8.26 T29 digital input 6 destination Pr 14.08
8.39
T28 and T29 digital input auto selection disable On (1)
11.01 Define Pr 0.11 Pr 1.03
11.02 Define Pr 0.12 Pr 2.01
11.03 Define Pr 0.13 Pr 4.02
11.04 Define Pr 0.14 Pr 0.00
11.05 Define Pr 0.15 Pr 7.11
11.06 Define Pr 0.16 Pr 7.15
11.07 Define Pr 0.17 Pr 7.01
11.08 Define Pr 0.18 Pr 7.02
11.09 Define Pr 0.19 Pr 7.03
11.10 Define Pr 0.20 Pr 14.10
11.11 Define Pr 0.21 Pr 14.11
11.12 Define Pr 0.22 Pr 14.12
11.13 Define Pr 0.23 Pr 14.13
11.14 Define Pr 0.24 Pr 14.14
11.15 Define Pr 0.25 Pr 14.15
11.16 Define Pr 0.26 Pr 1.27
11.17 Define Pr 0.27 Pr 1.28
11.18 Define Pr 0.28 Pr 7.12
11.19 Define Pr 0.29 Pr 7.16
11.20 Define Pr 0.30 Pr 14.09
14.02 Main reference source Pr 7.01
14.03 PID reference source Pr 1.27
14.04 PID feedback source Pr 1.28
14.16 PID output destination Pr 1.36
