Performance RFC mode
166 Unidrive SP Advanced User Guide
www.controltechniques.com Issue Number: 10
Open-loop, closed-loop vector and servo
Table 5-7
Regen
Table 5-8
OFF (0) = Terminal inactive
On (1) = Terminal active
Terminal + type
I/O state Invert Source / destination Output select
Pr Pr Default Pr Default Pr Default
T24 input / output 1 Pr 8.01 Pr 8.11 0Pr 8.21 Pr 10.03 - Zero speed Pr 8.31 1
T25 input / output 2 Pr 8.02 Pr 8.12 0Pr 8.22 Pr 10.33 - Drive reset Pr 8.32 0
T26 input / output 3 Pr 8.03 Pr 8.13 0Pr 8.23 Pr 6.30 - Run forward Pr 8.33 0
T27 input 4 Pr 8.04 Pr 8.14 0Pr 8.24 Pr 6.32 - Run reverse
T28 input 5 Pr 8.05 Pr 8.15 0Pr 8.25 Pr 1.41 – Local/remote
T29 input 6 Pr 8.06 Pr 8.16 0Pr 8.26 Pr 6.31 – Jog
T41 / 42 Relay Pr 8.07 Pr 8.17 0Pr 8.27 Pr 10.01 – Drive ok
T22 24V output Pr 8.08 Pr 8.18 1Pr 8.28 Pr 0.00
T31 Secure disable Pr 8.09
Terminal + type
I/O state Invert Source / destination Output select
Pr Pr Default Pr Default Pr Default
T24 input / output 1 Pr 8.01 Pr 8.11 0Pr 8.21 Pr 3.09 - Enable motor drive Pr 8.31 1
T25 input / output 2 Pr 8.02 Pr 8.12 0Pr 8.22 Pr 3.08 - Contactor closed Pr 8.32 0
T26 input / output 3 Pr 8.03 Pr 8.13 0Pr 8.23 Pr 10.01 – Drive ok Pr 8.33 1
T27 input 4 Pr 8.04 Pr 8.14 0Pr 8.24 Pr 0.00 - Not used
T28 input 5 Pr 8.05 Pr 8.15 0Pr 8.25 Pr 0.00 - Not used
T29 input 6 Pr 8.06 Pr 8.16 0Pr 8.26 Pr 0.00 - Not used
T41 / 42 Relay Pr 8.07 Pr 8.17 0Pr 8.27 Pr 3.07 – Close contactor
T22 24V output Pr 8.08 Pr 8.18 1Pr 8.28 Pr 0.00 - Not used
T31 Secure disable Pr 8.09
8.01 T24 digital I/O 1 state
8.02 T25 digital I/O 2 state
8.03 T26 digital I/O 3 state
8.04 T27 digital input 4 state
8.05 T28 digital input 5 state
8.06 T29 digital input 6 state
8.07 Relay status
8.08 T22 24V output state
8.09 Drive enable indicator
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Default
Open-loop, Closed-loop vector, Servo,
Regen
See table
Update rate 4ms write
