Page #242 background imageLoading...
Page #242 background image
Interface to the encoder
242
© 2022 KEB Automation KG
This parameter is bit-coded:
ec35
pos. calc mode
Bit
Function
Value
Function
0
Evaluation high-resolution
(at 1Vss signals)
0
High-resolution is evaluated.
1
High-resolution is not evaluated.
1
Rotation of the position and
speed
0
not inverted
2
inverted
2
Resolver evaluation com-
patibility mode
0
Improved resolver evaluation (from V2.6)
4
Previous resolver evaluation (up to V2.5)
3..4
Only for F6P and S6P de-
vices and only for ec16 =
21: "Inductive Sensors":
Evaluation signal tracks
0
Tracks A and B are evaluated
8
Only track A is evaluated
16
Only track B is evaluated
5
Only for F6P and S6P de-
vices and only for ec16 =
21: "Inductive Sensors":
Display of signal levels
0
off
32
on
Encoder breakage recognition
The encoder signals, which shall be evaluated via ec16 are tested after switched
on and cyclically in operation, whether they correspond to the specifications (e.g.,
RS485 or 1Vss).
A warning is triggered, if deviations from the specifications are detected. An error
message is triggered in ec00, if these deviations occur too often.
Whether the axis module changes into error state through this error message of
the encoder interface depends on the programming of the pn parameters and the
used control mode (cs00).
Pure digital encoder evaluations (ec16 = Endat digital, BiSS and SSI) recognize an
interrupted signal line of 10 ms and lower.
The disconnecting time is depending on the adjusted encoder type, the signal lev-
els, signal frequency and position for the evaluation of analog signals.
In an extreme case (e.g.) if a COS line is interrupted at a position where the signal
would have a signal difference of 0V, no encoder breakage can be recognized at
all!
6.1.6.3 Speed smoothing
The total speed deceleration is calculated by:
ec26 speed scan time / 2 + ec27 speed PT1-time
Speed scan time ec26 speed scan time
This parameter determines the time between the measured positions wherefrom
the speed is generated.
Index
Id-Text
Name
Function
0x281A
0x481A
ec26
speed scan time
Scan time for speed
