Motor parameterization

299

Magnetizing current

6.2.5.1 Magnetizing current asynchronous motor

The rated magnetizing current of an asynchronous motor can be calculated via the

cos(phi) and the rated current or specified directly via parameter dr08.

With the automatic calculation of cos (phi) at major motors (> 30kW) one obtain of-

ten too high magnetizing current. This high current causes additional stator losses

and the drive reaches the voltage limit faster at higher speeds. Since the increased

current must be reduced again via the maximum voltage controller causes negative

effects in the dynamic operation.

The actual calculation is based on the accuracy of the type plate data, especially of

the rated current.

dr08

magnetizing current %

0X2208

Value

Meaning

off

Current is calculated automatically

0.1…100%

Magnetizing current in % of the rated motor current
