4.2 Manager Programming
Extension Number Set
003
4-20 System Programming
Description Assigns an extension number to each extension.
Selection • Jack number: KX-TD816 – 01 through 16 (-1 / -2)
KX-TD1232 – 01 through 64 (-1 / -2)
(-1 = first part, -2 = second part)
• Extension Number: 2 through 4 digits
Default KX-TD816: Jack 01-1 through 16-1 = 201 through 216;
Jack 01-2 through 16-2 = 301 through 316
KX-TD1232:Jack 01-1 through 64-1 = 201 through 264;
Jack 01-2 through 64-2 = 301 through 364
Programming 1. Enter 003.
Display: EXT Number Set
2. Press NEXT.
Display: Jack NO?—>
3. Enter a jack number.
To enter jack number 01, you can also press NEXT.
To select the second part (-2), press NEXT after entering a jack
number.
Display: #01-1:EXT201
4. Enter an extension number.
To change the current entry, press CLEAR and the new number.
5. Press STORE.
6. To program another jack, press NEXT or PREV, or
SELECT and the desired jack number.
7. Repeat steps 4 through 6.
8. Press END.
Conditions • There is a maximum of 32 extension numbers for KX-TD816, and 128
extension numbers for KX-TD1232. Each extension number can be
two, three, or four digits, consisting of 0 through 9. The and # keys
cannot be used.
• In the case of KX-TD1232, jack numbers 01 through 32 are for the
Master System and 33 through 64 are for the Slave, if available.
