4.6 CO Line Programming
DIL 1:1 Extension — Day / Night
4-88 System Programming
407-408
Description The Direct In Lines (DIL) 1:1 feature allows incoming outside calls
to be directed to a specific extension. When a CO line is assigned
as DIL 1:1, it is necessary to assign the destination. These
programs specify the extension number for day or night mode.
Selection • CO line number:
KX-TD816 – 01 through 08, ( =all CO lines)
KX-TD1232 – 01 through 24, ( =all CO lines)
• Extension number: 2 through 4 digits / Disable (no DIL 1:1)
Default All CO lines – Disable — Day / Night
Programming 1. Enter a program address (407 for day or 408 for night).
Display example: DIL 1:1 Asn Day
2. Press NEXT.
Display: CO Line NO?–>
3. Enter a CO line number.
To enter CO line number 01, you can also press NEXT.
Display example: CO01:Disable
4. Enter an extension number.
To change the current entry, press CLEAR and the new number.
To disable DIL 1:1, press CLEAR.
5. Press STORE.
6. To program another CO line, press NEXT or PREV, or
SELECT and the desired CO line number.
7. Repeat steps 4 through 6.
8. Press END.
Conditions • In the case of KX-TD1232, CO01 through CO12 are for the Master
System and CO13 through CO24 are for the Slave, if available. CO
line numbers in the out-of-service system are unacceptable.
• To assign all CO lines to one selection, press the key at step 3. In
this case, the display shows the contents programmed for CO01.
• You set the extension numbers in program [003] “Extension Number
Set” or floating numbers of pagers and the modem in program [813]
“Floating Number Assignment.”
• If a CO line is also programmed for DIL 1:N in program [603]–[604]
“DIL 1:N Extension and Delayed Ringing — Day / Night,” it is
regarded as a DIL 1:1 line.
Feature References Section 3, Features,
Direct In Lines (DIL) Night Service
