4.8 Extension Programming
EXtra Device Port
600
4-114 System Programming
Description EXtra Device Port (XDP) allows a single line telephone (SLT) to be
connected to the same jack as a digital proprietary telephone
(DPT). This program assigns which jacks are XDP. The SLT and
DPT of the programmed jack work as independent extensions.
Selection • Jack number: KX-TD816 – 01 through 16, ( =all jacks)
KX-TD1232 – 01 through 64, ( =all jacks)
• Disable / Enable
Default All jacks – Disable
Programming 1. Enter 600.
Display: XDP Assign
2. Press NEXT.
Display: Jack NO?->
3. Enter a jack number.
To enter jack number 01, you can also press NEXT.
Display example: #01:Disable
4. Keep pressing SELECT until the desired selection is
displayed.
5. Press STORE.
6. To program another jack, press NEXT or PREV, or
SELECT and the desired jack number.
7. Repeat steps 4 through 6.
8. Press END.
Conditions • In the case of KX-TD1232, jack numbers 01 through 32 are for the
Master System and 33 through 64 are for the Slave, if available.
• To assign all jacks to one selection, press the key at step 3. In this
case, the display shows the contents programmed for Jack 01.
• Immediately after changing your assignment, changed setting may not
work for a maximum of eight seconds.
Feature References Section 3, Features,
EXtra Device Port (XDP)
