4.6 CO Line Programming
CPC Signal Detection Incoming Set
4-86 System Programming
405
Description Assigns the expected minimum duration of the CPC Signal on
incoming outside calls. If this is programmed, the system
disconnects the line when the CPC Signal is detected.
Selection • CO line number:
KX-TD816 – 01 through 08, ( =all CO lines)
KX-TD1232 – 01 through 24, ( =all CO lines)
• Time (milliseconds): Disable (no detection) / 02 through 75 (
✕ 8
is the actual time)
(See the table on the following page.)
Default All CO lines – 44 (352 ms)
Programming 1. Enter 405.
Display : CPC Detection
2. Press NEXT.
Display: CO Line NO?→
3. Enter a CO line number.
To enter CO line number 01, you can also press NEXT.
Display example: CO01:44
4. Enter the time, or press CLEAR to select “Disable.”
To change the current entry, press CLEAR and the new time.
5. Press STORE.
6. To program another CO line, press NEXT or PREV, or
SELECT and the desired CO line number.
7. Repeat steps 4 through 6.
8. Press END.
Conditions • CPC Signal Detection is effective only with the 4-DID Line Unit (KX-
TD185) (KX-TD816: CO05 through CO08, KX-TD1232: CO09
through CO12 – Master / CO21 through CO24 – Slave). In this case,
“D (4DID)” must be selected in program [109] “Expansion Card / Unit
Type.”
• To assign all CO lines to one selection, press the key at step 3. In
this case, the display shows the contents programmed for CO01.
• You may disable CPC Signal Detection for a CO line.
• Program [415] “CPC Signal Detection Outgoing Set” is used to
program CPC Signal Detection for outgoing outside calls.
To Next Page
