4.6 CO Line Programming
CO Line Connection Assignment
System Programming 4-81
400
Description Used to identify the CO lines which are connected to the system(s).
This prevents users from originating a call to a line which is not
connected.
Selection • CO line number:
KX-TD816 – 01 through 08, ( =all CO lines)
KX-TD1232 – 01 through 24, ( =all CO lines)
• Connect / No Connect
Default All CO lines – Connect
Programming 1. Enter 400.
Display: CO Connection
2. Press NEXT.
Display: CO Line NO?–>
3. Enter a CO line number.
To enter CO line number 01, you can also press NEXT.
Display example: CO01:Connect
4. Keep pressing SELECT until the desired selection is
displayed.
5. Press STORE.
6. To program another CO line, press NEXT or PREV, or
SELECT and the desired CO line number.
7. Repeat steps 4 through 6.
8. Press END.
Conditions • In the case of KX-TD1232, CO01 through CO12 are for the Master
System and CO13 through CO24 are for the Slave, if available.
• To assign all CO lines to one selection, press the key at step 3. In
this case, the display shows the contents programmed for CO01.
Feature References Section 3, Features,
CO Line Connection Assignment
