4.6 CO Line Programming
CO Line Name Assignment
419
Description Used to set names to CO lines. The preset name is shown on a
display proprietary telephone when an incoming outside call is
placed to the telephone.
Selection • CO line number:
KX-TD816 – 01 through 08, ( =all CO lines)
KX-TD1232 – 01 through 24, ( =all CO lines)
• Name: 10 characters (max.)
Default All CO lines – Not stored
Programming 1. Enter 419.
Display: CO Line Name
2. Press NEXT.
Display: CO Line NO?–>
3. Enter a CO line number.
To enter CO line number 01, you can also press NEXT.
Display example: CO01:Not Stored
4. Enter a name.
For entering characters, see Section 4.1.3 “Entering Characters.”
To delete the current entry, press CLEAR.
To change the current entry, press CLEAR and the new name
5. Press STORE.
6. To program another CO line, press NEXT or PREV, or
SELECT and the desired CO line number.
7. Repeat steps 4 through 6.
8. Press END.
Conditions • In the case of KX-TD1232, CO01 through CO12 are for the Master
System and CO13 through CO24 are for the Slave, if available.
• There is a maximum of 24 names. Each name has a maximum of 10
characters.
• To assign all CO lines to one selection, press the key at step 3. In
this case, the display shows the contents programmed for CO01.
Feature References Section 3, Features,
Display, Call Information
4-100 System Programming
