4.6 CO Line Programming
Pay Tone Assignment*
4-107-i System Programming
436
*: Available for KX-TD1232 only.
Description Enables Pay Tone of the Central Office. Your Central Office sends
the pay tone or the ISDN S0 line sends pay message so that the
counting for fee starts for the call.
Selection • CO line number: 01 through 24, ( =all CO lines)
• Enable / Disable
Default All CO lines – Disable
Programming 1. Enter 436.
Display: Pay-Tone Asn
2. Press NEXT.
Display: CO Line NO?→
3. Enter a CO line number.
To enter CO line number 01, you can also press NEXT.
Display example: CO01:Disable
4. Keep pressing SELECT until the desired selection is
displayed.
5. Press STORE.
6. To program another CO line, press NEXT or PREV, or
SELECT and the desired CO line number.
7. Repeat steps 4 through 6.
8. Press END.
Conditions • An optional 4-CO Line Unit (KX-TD180D) or 8-CO Line Card (KX-
TD181D) must be installed to receive the pay tone.
• An optional 2-ISDN S0 Line Unit (KX-TD280) or 4-ISDN S0 Line
Card (KX-TD281) must be installed to receive pay message.
• In the case of KX-TD1232, CO01 through CO12 are for the Master
System and CO13 through CO24 are for the Slave.
• To assign all CO lines to one selection, press the key in step 3. In
this case, the display shows the contents programmed for CO01.
Feature References Section 3, Features,
HOTEL APPLICATION
