4.8 Extension Programming
Doorphone Ringing Assignment — Day / Night
607-608
4-122 System Programming
Description These programs assign the extensions which will ring when a
doorphone call is received during the day and night modes.
Programmed extensions are also allowed to open the door.
Selection • Jack number: KX-TD816 – 01 through 16, (-1 / -2),
KX-TD1232 – 01 through 64, (-1 / -2),
( =all jacks, -1 = first part, -2 = second part)
• Doorphone number:
KX-TD816 – 1 and 2, two entries (max.)
KX-TD1232 – 1 through 4, four entries (max.)
Default Jack 01-1– All doorphones; Other jacks – no doorphone — Day /
Night
Programming 1. Enter a program address (607 for day or 608 for night).
Display example: Doorphone in Day
2. Press NEXT.
Display: Jack NO?->
3. Enter a jack number.
To enter jack number 01, you can also press NEXT.
To select the second part (-2), press NEXT after entering a jack
number.
Display example: #01-1:1234
4. Enter the doorphone numbers.
To assign no doorphone, press CLEAR.
To change the current entry, press CLEAR and the new doorphone
numbers.
5. Press STORE.
6. To program another jack, press NEXT or PREV, or
SELECT and the desired jack number.
7. Repeat steps 4 through 6.
8. Press END.
Conditions • In the case of KX-TD1232, jack numbers 01 through 32 are for the
Master System and 33 through 64 are for the Slave, if available.
• For an explanation of jack numbering, see “Rotation of jack number”
on page 4-7.
