4.11 Option Programming
System Additional Information
990
4-138 System Programming *: CO numbers [9] through [24] in the field number [23]
are available for KX-TD1232 only.
Description Adds the following programming items, if required:
Display
example
0010100011000101
Field number
(10) (9) (8) (7) (6) (5) (4) (reserved) (3) (2) (1)
↓↓ ↓ ↓ ↓↓↓ ↓ ↓↓↓
Area 1 There are 10 fields available in Area 1 as follows:
Display
example
1110011001101100
Field number
(unused)(26)(22) (21) (20)(19)(18)(17)(16)(15)(14)(13)(12)(11)
↓ ↓↓ ↓ ↓↓↓↓↓↓↓↓↓↓
Area 2 There are 13 fields available in Area 2 as follows:
Display
example
0000000000000000
Field number
[16][15][14][13][12][11][10] [9][8] [7] [6] [5] [4] [3] [2] [1]
↓↓↓↓↓↓↓↓↓↓↓↓↓↓↓↓
CO number
(23)*
↓
Area 4 KX-TD1232 – [17] through [24] below match CO lines 17 through 24:
Display
example
1111111100000000
CO number
[24][23][22][21][20][19][18][17]
↓↓↓↓↓↓↓↓
(reserved) (27)( )(25)(24) (23)*
Field number
↓↓↓↓↓ ↓
Area 3 KX-TD816 – [1] through [8] below match CO lines 1 through 8:
KX-TD1232 – [1] through [16] below match CO lines 1 through 16:
un-
used
