2.4.12 Battery Adaptor Connection
2. Insert the plug of the battery adaptor into
the battery adaptor connector on the
main unit.
Connect the earth wire to the earth
terminal on the main unit.
User-supplied car batteries can be used as a backup power supply
in the event of a power failure. In case of power failure, the
batteries automatically maintain the power to the main unit
instantly. The optional Battery Adaptor, model KX-A46, is
required.
The Battery Adaptor should not be exposed to direct sunlight.
Keep the adaptor and car batteries away from heating appliances
and fire. Place car batteries in airy place.
Connection
When connecting the battery adaptor, keep the following in mind.
•Make sure of the polarities of batteries and wires.
•Make sure do not short the batteries and wires.
•To connect the two batteries, use accessory wire.
1. Assemble the cords and two car batteries
(12VDC each) as shown.
3. Turn on the power switch of the battery
adaptor.
