4.8 Extension Programming
DIL 1:N Extension and Delayed Ringing — Day / Night
603-604
4-118 System Programming
Description A DIL 1:N line can be assigned to ring more than one extension.
All incoming calls from the programmed CO lines are directed to
the specified extensions. These programs assign the extensions and
the notification method for each CO line in both day and night
modes.
Selection • Jack number: KX-TD816 – 01 through 16, (-1 / -2),
KX-TD1232 – 01 through 64, (-1 / -2),
( =all jacks, -1 = first part, -2 = second part)
• CO line number:
KX-TD816 – 01 through 08, ( =all CO lines)
KX-TD1232 – 01 through 24, ( =all CO lines)
• Disab (disable) / Immdt (immediate ringing) / 4RNG (4 ring
delay) / 6RNG (6 rings delay) / 8RNG (8 rings delay) / No RNG
(no ring)
Default All jacks-1/2 – all CO lines – Immediate ringing — Day / Night
Programming 1. Enter a program address (603 for day or 604 for night).
Display example: DIL 1:N Asn Day
2. Press NEXT.
Display: Jack NO?->
3. Enter a jack number.
To enter jack number 01, you can also press NEXT.
To select the second part (-2), press NEXT after entering a jack
number.
Display example: #01-1:CO01:Immdt
4. Enter the CO line number.
You can also keep pressing or until the desired CO line
number is displayed.
5. Keep pressing SELECT until the desired selection is
displayed.
6. Press STORE.
7. To program another jack, press NEXT or PREV, or SELECT
and the desired jack number.
To Next Page
