*: Available for KX-TD1232 only. Installation 2-49
2.4.10 System Connection*
To connect two main units, use the optional System Inter
Connection Cards (two) and the Connection Cable (included in the
cards).
1. Insert the upper end of the System Inter Connection
Card into the two hooks on the main unit of the
Master System.
2. Press the two corners at the lower end of the
System Inter Connection Card.
3. Connect the cord to the System Inter Connection
Card connector.
4. Open the latch on the card.
5. Repeat steps 1 through 4 for the Slave System,
using the other card.
6. Insert one connection cable end to the Master
System and insert the other end into the Slave
System.
7. Close the latches on both systems.
System Inter Connection Card
Connection Cable
To Next Page
