4.6 CO Line Programming
DTMF Time
System Programming 4-85
404
Description A CO line set to DTMF mode in program [402] “Dial Mode
Selection” can have two settings. This program sets the duration of
the DTMF signals sent to a CO line set to DTMF mode.
Selection • CO line number:
KX-TD816 – 01 through 08, ( =all CO lines)
KX-TD1232 – 01 through 24, ( =all CO lines)
• Time (milliseconds): 80 / 160
Default All CO lines – 80 ms
Programming 1. Enter 404.
Display: DTMF Time
2. Press NEXT.
Display: CO Line NO?–>
3. Enter a CO line number.
To enter CO line number 01, you can also press NEXT.
Display example: CO01: 80msec
4. Keep pressing SELECT until the desired selection is
displayed.
5. Press STORE.
6. To program another CO line, press NEXT or PREV, or
SELECT and the desired CO line number.
7. Repeat steps 4 through 6.
8. Press END.
Conditions • In the case of KX-TD1232, CO01 through CO12 are for the Master
System and CO13 through CO24 are for the Slave, if available.
• To assign all CO lines to one selection, press the key at step 3. In
this case, the display shows the contents programmed for CO01.
• The DTMF time required is determined by the CO line or PBX line.
Feature References Section 3, Features,
Dial Type Selection
