Tektronix DPO5000 Series User Manual

Analyzing waveforms Save the event table
Learn a bout the Protocol Decode Event Table. (see page 370)
Save the event table
From the Analyze menu, select Protocol Decode Event Table. Click the Export button to open the Select
the columns to Copy/Export dialog box. From the dialog box, click the Export button.
Overview
Use this dialog box to export (save) the contents of the event table to a specified fi le in comma sepa rated
values (CSV) format.
To use
To save to a file,enteraNameorusethedefaultfi le name. The file extension specified in the Save as
type list will automatically be appended to the file name.
Behavior
This dialog box opens when you click Export from the Select the columns to Copy/Export dialog box.
The default file type is a file w ith comma separated values (.csv).
The default folder is
C:\Users\[Username]\Tektr onix\TekScope\da ta.
NOTE. Any characters that you enter in the file name box become part of the file name. The instrument
does not use any user-defined file extensions.
376 DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series
