About Tektronix oscilloscopes Application-Specific measurements
Application-Specific measurements
You can load optional measurement extensions as needed to enhance the capabilities of the instrument
for specific applications. These applications build on the precision signal acquisition performance of the
instrument t
o address your specific design requirements.
Here are some examples of the application packages:
Jitter and Timing Analysis. Use the DPOJET software to characterize the timing performance
of semiconductor systems. Analyze clock jitter, setup and hold times, and many other timing
measureme
nts on a cycle-by-cycle basis over long, single-shot acquisitions. Measurement statistics are
presented as numerical statistics, or graphically in a histogram, cycle trend, time trend, or spectral plot.
Ethernet
Compliance Testing. Use the ET3 software to perform 10/100/1000 Base T Ethernet
compliance testing.
USB Sign
als. Use the USB or USB3 software to characterize USB 2.0 or USB 3.0 universal serial bus
signals, including mask testing and parametric testing.
Power M
easurements. Use the DPOPWR software to quickly measure and analyze power dissipation
in power supply switching devices and magnetic components.
DDR Mem
ory Bus Analysis. Automatically identify DDR1, LP-DDR1 DDR2, DDR3, and GDDR3
Reads and Writes and make JEDEC conformance measurements with pass/fail results on all edges in
every Read and Write burst.
MIPI® D-PHY Characterization and Compliance Testing. Verify to the D-PHY specification,
rapidly characterize and discover sources of jitter and signal integrity concerns.
SignalVu™ Vector Signal Analysis. Eas ily validate wideband designs and characterize wideband
spectral events.
CAN and LIN Timing and Protocol Decode Software. When you need to ensure seamless and
reliable operation of a CAN or LIN network, this option enables CAN bus triggering and provides
the solution to measure oscillator tolerance, propagation delay, and simultaneously decode CAN and
LIN messages, with the protocol leveraging the trigger c apabilities.
8b10b Serial Triggering and Analysis. Use the 8b10b software to trigger on and analyze 8b10b
serial b us signals.
Additional p ackages may be available. Contact your Tektronix representative for more information.
DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 53
