4.13.7.2 Physical description (see Figure 4.49 )
Connectors
The connector J2 is reserved for factory tests.
This card has no external connections.
Indicators The indicators are located on the card circuit and not on the front panel.
TABLEAU 4.67 PRESENTATION OF THE CP1 CARD INDICATORS
4.13.7.3 Hardware configuration
Jumper SW1 must be configured as shown on the diagram, with slots 1 and 2 connected
together.
4.13.7.4 Installation and wiring
This card has no external connections.
NAME STATE EXPLANATION
CR1 (red) On steady Incorrect operation
CR2 (red) Flashing rapidly Card in service
