Installation and Maintenance Manual - Aastra 5000 AMT/PTD/PBX/0058/4/6/EN
Description et caractéristiques d’un PBX 01/2011 Page 59
Figure 3.13 Overview of an A3XL cabinet
expansion cabinet
Connection cable
AXL-A2XL-A3XL
Second
expansion cabinet
First
Main rack
Power supply modules
RUCV-L cards
UCV-L card
Blanking plates
(empty slots)
Cards
expansion cabinet
