AMT/PTD/PBX/0058/4/6/EN Installation and Maintenance Manual - Aastra 5000
Page 370 01/2011 Installation and activation
6.6 Viewing the IP address in case of loss (offline)
Access via the web interface will no longer be possible if the system's IP parameter value
is lost.
In this case, consultation in serial mode is available from a Windows PC equipped with the
"Hyperteminal” application.
Access is provided locally on the COM port of the CPU card, using a NULL MODEM cable
connected between the COM port of the CPU card and the PC COM port.
• Open a Hyperterminal window and configure the connection as follows:
- Bits per second: 115200 bits/s
- Data bits: 8
- Parity: none
- Stop bits: 1
- Flow control: None
• Restart the cabinet.
• Upon display of "Identification starting"
•Press Ctrl + I
• The screen then displays the different configuration modes.
• Select "S" mode to display the network configuration.
• The screen then displays the cabinet’s network configuration.
• Enter "N" in this screen and in the next ones if the configuration should not be modified.
Configuration mode (F/T/S/P/E)
- F: Factory mode
- T: Total mode
- S: Standard mode
- P: Password reset
- E: for Exit
