AMT/PTD/PBX/0058/4/6/EN Installation and Maintenance Manual - Aastra 5000
Page 280 01/2011 Description des sous-ensembles
4.14.11 LH16X card
4.14.11.1Description
The LH16X card is used to connect 16 analogue hotel terminals to An Aastra XL/XS iPBX.
The LH16X card offers the same features as the LA16X card, plus an extra feature that
lights up an LED on sets if messages have been left (for hotel configuration).
4.14.11.2Functional description
The LH16X card has the same features as the LA16X card (see Section4.14.1.2), plus an
extra feature that lights up an LED to inform the user connected that a message has been
left (example of use: hotel customer reception).
The LED signal command is sent to the central unit (UCV card), which activates a high
voltage current generator built into the card providing the power supply (105 V DC)
required for the operation of the lamps on hotel sets.
Figure 4.60 O
VERVIEW OF THE LH16X CARD
4.14.11.3Physical description (see Figure 4.51 )
Connectors
L
1
5
L
7
L
8
L
0
L
N
1
6
X
A15
A8
J1
P
B
X
_
M
A
T
R
I
X
_
X
L
_
L
H
1
6
X
R
J
_
C
O
T
E
_
0
1
_
0
1
A7
A0
LH16X CARD
