AMT/PTD/PBX/0058/4/6/EN Installation and Maintenance Manual - Aastra 5000
Page 58 01/2011 Description et caractéristiques d’un PBX
Figure 3.12 Overview of an A2XL cabinet
Expansion cabinet
RUCV-L card
Connection cable
AXL-A2XL
Power supply modules
Expansion cards
UCV-L card
Blanking plates
(empty slots)
Main rack
