AMT/PTD/PBX/0058/4/6/EN Installation and Maintenance Manual - Aastra 5000
Page 88 01/2011 Description et caractéristiques d’un PBX
* The LD4, LD4N, LD4X and LT2 synchronising cards must be located in slots 0 to 5 of the main cabinet when they are
to be used to provide the reference clocks for the main card.
TABLEAU 3.8 POSSIBLE BASIC AXL IPBX BACK PLANE EQUIPMENT
CONFIGURATION
AXL main cabinet
BACKPLANE SLOT 1-00 1-01 1-02 1-03 1-04 1-05 1-06 1-07 1-08 1-09 1-10 1-11 1-12 1-13
SYNCHRONISING
POSITION
0
(H0)
1
(H1)
2
(H2)
3
(H3)
4
(H4)
5
(H5)
NO NO NO NO NO NO NO NO
CLX cards
LD4/LD4N/LD4X
without ADPCM*
Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
LD4/LD4N with
ADPCM
#8 #9 #10 #11 #12 #13 Yes Yes Not Not Not Not Not Not
LD4X with ADPCM Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
LT2* Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
IPS Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
PT2 without VOIP Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
PT2 8 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
PT2 16 #8 #9 #10 #11 #12 #13 Yes Yes Not Not Not Not Not Not
PT2 32 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
CS1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
CA1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
CP1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
MUM Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Equipment cards
LA16X Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
LA16X-8 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
LA8 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
LN16X Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
LN16X-8 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
LN8 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
LM8 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
LH8 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
LH16X Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
LH16X-8 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
LR4 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
LI1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
BTX Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
