HCS01.1E-W0003, -W0006, -W0009, -W0013, -W0018-A-02
Nominal voltage of mains filter: 1 × 230 V
Clock frequency
[kHz]
Leakage capacitance (motor + ca‐
ble)
[nF]
Mains filters EMC limit value class to be ach‐
ieved
(IEC / EN 61800-3)
4; 8 < 90
NFE02.1
1)
FN350 (Schaffner)
C2
4; 8 90 < … < 120 C3
12 < 20 C2
12 20 < … < 40 C3
1) Only allowed up to a nominal current of 8 A
Tab. 4-38: Mains filter; 1 × 230 V
HCS01.1E-W0005, -W0008, -W0018-A-03, -W00028, -W00054, (mains voltage: 3 × 400 V, L1-L2-L3)
can be combined with
1)
HCS01.1E-W0003, -W0006, -W0009, -W0013, -W0018-A-02, (mains voltage: 1 × 230 V, L-N)
Nominal voltage of mains filter: 3 × 400 V + N
Clock frequency
[kHz]
Leakage capacitance (motor + ca‐
ble)
[nF]
Mains filters EMC limit value class to be ach‐
ieved
(IEC / EN 61800-3)
4 < 70 FN3280H (Schaffner) C2
4 70 < … < 120 C3
4 < 70 FN3256H (Schaffner) C3
8 < 40 FN3280H (Schaffner) C2
8 40 < … < 70 C3
8 < 40 FN3256H (Schaffner) C3
12 < 20 FN3280H (Schaffner) C2
1) This combination allows 3-phase and 1-phase HCS01 devices
to be interconnected at one common 4-phase mains filter.
Thereby, the nominal current of the mains filter and the maxi‐
mum allowed leakage capacitance are taken into account.
Tab. 4-39: Mains filter; 3 × 400 V + N
Limit Value Classes
IEC / EN
61800-3
CISPR 11
(EN55011)
Explanation Curves of
limit value
character‐
istic
Category C4,
2nd environ‐
ment
None One of the following 3 requirements must have been fulfilled: Mains con‐
nection current >400 A, IT mains or required dynamic drive behavior not
reached by means of EMC filter. Adjust limit values to use and operation
on site. User has to carry out and provide evidence of EMC planning.
-
Category C3,
2nd environ‐
ment
Class A; Group
2
I > 100 A
Limit value in industrial areas to be complied with for applications operat‐
ed at supply mains with nominal currents > 100 A.
1.1
1.2
DOK-INDRV*-HCS01******-PR05-EN-P Bosch Rexroth AG 99/341
Rexroth IndraDrive CsDrive Systems with HCS01
Combining the individual components
