8.3 Additional components
8.3.1 Transformers
General information
Transformers are only needed when the mains voltage is outside of the al‐
lowed nominal voltage of the drive controller.
Grounded mains
For grounded mains, the mains voltage is adjusted to the nominal voltage of
the device by means of autotransformers which have been sized for a specif‐
ic output voltage range.
Ungrounded mains
For voltage adjustment of ungrounded mains, always connect isolating trans‐
formers to prevent overvoltages between outer conductor and ground.
Autotransformers for drive controllers
Types
Short type designation 1 2 3 4 5 6 7 8 9
1
0 1 2 3 4 5 6 7 8 9
2
0 1 2 3 4 5 6 7 8 9
3
0 1 2 3 4 5 6 7 8 9
4
0
Example: T R A F O D S T ■ 4 , 0 0 / S / 3 8 0 , 4 1 5 , 4 4 0 - 2 2 0 1 0 M M
① ② ③ ④ ⑤ ⑥ ⑦
① Object:
TRAFO = transformer
② Product:
DST = AC autotransformer
③ Nominal power:
■2,00 = 2.0 kVA
■2,50 = 2.5 kVA
■4,00 = 4.0 kVA
■5,00 = 5.0 kVA
■7,50 = 7.5 kVA
④ Type of construction (design):
S = upright mounting
⑤ Nominal input voltage (phase-phase):
e.g., 380,415,440 = AC 380 V, AC 415 V, AC 440 V
⑥ Nominal output voltage (phase-phase):
e.g., 220 = 230 V
⑦ Special design:
e.g., 10MM = maximum conductor connection cross section 10 mm
2
Tab. 8-23: DST, type code
Bosch Rexroth AG DOK-INDRV*-HCS01******-PR05-EN-P290/341
Rexroth IndraDrive CsDrive Systems with HCS01
Cables, accessories, additional components
