Bosch Rexroth IndraDrive CsDrive System with HCS01 User Manual

Combination of HCS01 and MSM/MSK
HCS01
3 AC 110 … 230 V 3 AC 200 … 500 V
W0003 W0006 W0009 W0013 W0018 W0005 W0008 W0018 W0028 W0054
MSM
MSM019 … MSM041
■ T - -
MSK
MSK030 …
MSK070C-0150
□ ■ □
MSK
MSK070C-0300
… MSK103
- □ ■
■ Optimum combination
□ Some allowed combinations are possible
T Allowed combination (transformer required, as operation of
MSM only allowed with a maximum of 3 AC 230 V)
- Combination not allowed
Tab. 1-5: Converter HCS01 and Motors MSM/MSK
Drive sizing with Rexroth IndraSize
Rexroth IndraSize is a software for optimum sizing of a drive sys‐
tem consisting of the components Rexroth IndraDrive and Indra‐
Dyn.
Rexroth IndraSize is available as a download.
Interfaces
Overview
● Compatible with IndraDrive platform
● Ethernet-based communication with the following supported protocols:
– sercos III
– PROFINET IO
– EtherNet/IP
– EtherNet POWERLINK
– EtherCAT
● Alternative communication:
– PROFIBUS DP
– CANopen
● Optional safety technology
● Optional multi-encoder interface
● Optional encoder emulation
● Analog input
● Freely configurable digital inputs/outputs
Bosch Rexroth AG DOK-INDRV*-HCS01******-PR05-EN-P14/341
Rexroth IndraDrive CsDrive Systems with HCS01
System presentation
