Bosch Rexroth IndraDrive CsDrive System with HCS01 User Manual

Country of use: international except for USA/Canada
Fuse I
N
[A] Current carrying ca‐
pacity (× 0.87) I
Z(40)
[A]
Cross section A [mm
2
]
Installation type E
1 × 2 × 3 ×
16 10.4 16
16 12.4 16
20 16.10 1.5
25 21.75 2.5
35 29.58 4
50 37.41 6
63 52.20 10
80 69.60 16
100 87.87 25
125 109.62 35
160 133.11 50
200 170.52 70
250 207.06 95
315 240.12 120
355 277.53 150
400 316.68 185
425 374.10 240
500 432.39 300
160 272.83 2 x 70
200 331.30 2 x 95
250 384.19 2 x 120
250 444.05 2 x 150
315 506.69 2 x 185
400 598.56 2 x 240
400 691.82 2 x 300
160 358.09 3 x 70
200 434.83 3 x 95
200 504.25 3 x 120
250 582.81 3 x 150
250 665.03 3 x 185
315 785.61 3 x 240
400 908.02 3 x 300
Tab. 4-28: Line cross sections and fuses, E according to EN 60204-1:2006, Ta‐
ble 6, for 150mm² and more DIN IEC 60364-5-52:2004, Table B.
52-10
Bosch Rexroth AG DOK-INDRV*-HCS01******-PR05-EN-P90/341
Rexroth IndraDrive CsDrive Systems with HCS01
Combining the individual components
