Edition Notes
03 Changes in comparison to previous edition:
New contents
● Safety technology Safe Motion (optional module S4)
● Analog/digital I/O extension (optional module DA)
● HAS05.1-015-NNN-NN (snap-on ferrite) accessory
Revised contents
● Type code
– HCS01
– HLR01
● Revised information on fuses for individual and group supply
● Dimensioning of line cross sections and fuses:
Revised recommendations for fuses
● On-board connection point X24/X25
● Revised data tables of inputs/outputs (digital, analog)
