Electrical data
Single-ended
Data Symbol Unit min. typ. max.
Input voltage
U
ext
V 5 - 30
Current consumption at U
ext
I
ext
mA 25 -
25 + 3×I
out
Output voltage "high"
U
Out_High
V
U
ext
- 2V
-
U
ext
Output voltage "low"
U
Out_Low
V - - 1.5
Output current
I
Out
mA - - 40
Output frequency f MHz - 1 -
Overload protection - - Present
Short circuit protection - - Present
Tab. 7-9: Single-ended
RS422
Data Symbol Unit min. typ. max.
Output voltage "high"
U
Out_High
V 2.5 - 5
Output voltage "low"
U
Out_Low
V 0 - 0.5
Output current
I
Out
mA - - 20
Output frequency f MHz - 4 -
Overload protection - - Present
Short circuit protection - - Present
Tab. 7-10: Outputs, RS422
Data Symbol Unit min. typ. max.
Input voltage "high"
U
In_High
V 2.5 - 5
Input voltage "low"
U
In_Low
V 0 - 0.5
Input resistance (difference)
R
In_D
ohm 110 - 130
Input resistance
R
In
kOhm - 150 -
Output frequency f MHz - 4 -
Overload protection - - Present
Short circuit protection - - Present
Tab. 7-11: Inputs, RS422
Bosch Rexroth AG DOK-INDRV*-HCS01******-PR05-EN-P204/341
Rexroth IndraDrive CsDrive Systems with HCS01
Technical data of the components
