Bosch Rexroth IndraDrive CsDrive System with HCS01 User Manual

Country of use: international except for USA/Canada
Fuse I
N
[A] Current carrying ca‐
pacity (× 0.87) I
Z(40)
[A]
Cross section A [mm
2
]
Installation type B2
1 × 2 × 3 ×
100 86.13 35
125 102.66 50
160 129.63 70
200 155.73 95
200 179.22 120
224 195.75 150
250 221.85 185
315 258.39 240
355 294.93 300
125 207.41 2 × 70
160 249.17 2 × 95
160 286.75 2 × 120
200 313.20 2 × 150
200 354.96 2 × 185
250 413.42 2 × 240
315 471.89 2 × 300
100 272.22 3 × 70
125 327.03 3 × 95
160 376.36 3 × 120
160 411.08 3 × 150
200 465.89 3 × 185
200 542.62 3 × 240
250 619.35 3 × 300
Tab. 4-27: Line cross sections and fuses, B2 according to EN 60204-1:2006,
Table 6, for 150mm² and more DIN IEC 60364-5-52:2004, Table B.
52-4
International except for USA/
Canada; installation type E
Country of use: international except for USA/Canada
Fuse I
N
[A] Current carrying ca‐
pacity (× 0.87) I
Z(40)
[A]
Cross section A [mm
2
]
Installation type E
1 × 2 × 3 ×
2 1.6 2
4 3.3 4
6 5.0 6
10 8.3 10
DOK-INDRV*-HCS01******-PR05-EN-P Bosch Rexroth AG 89/341
Rexroth IndraDrive CsDrive Systems with HCS01
Combining the individual components
