Bosch Rexroth IndraDrive CsDrive System with HCS01 User Manual

Allowed Mounting Positions
Mounting posi‐
tion
Note
G1 Allowed without restrictions
G2 Allowed without restrictions
G3 Mains filter may only be loaded with 80% of the maximum allowed
continuous current
G4 Allowed without restrictions
G5 Mains filter may only be loaded with 80% of the maximum allowed
continuous current
Tab. 8-26: Allowed Mounting Positions
Electrical Data NFE / NFD
Using mains filters in mains grounded via outer conductor
When using mains filters NFD03 in mains grounded via outer con‐
ductor, use an isolating transformer between mains and mains fil‐
ter.
Maximum mains con‐
nection voltage of
mains 50…60 Hz
U
N
Nominal
mains
current
I
nenn
(1)
Number
of pha‐
ses
Mains filter type Terminal connectors (3) Power
dissipa‐
tion ap‐
prox.
Weig
ht
Type of
construc‐
tion
In V In A Flexible
[mm
2
]
Rigid
[mm
2
]
AWG W kg
AC 480V +10% 7 3 NFD
03.1-480-007
4 (3) 6 (3) AWG 12 3,9 0,7 Vertical
AC 480V +10% 16 3 NFD
03.1-480-016
4 (3) 6 (3) AWG 12 6,4 1,0 Vertical
AC 480V +10% 30 3 NFD
03.1-480-030
10 16 AWG 6 11,9 1,4 Vertical
AC 480V +10% 55 3 NFD
03.1-480-055
16 25 AWG 4 25,9 2,0 Vertical
AC 480V +10% 75 3 NFD
03.1-480-075
25 35 AWG 3 30,4 3,5 Vertical
AC 480V +10% 130 3 NFD
03.1-480-130
50 50 AWG 1/0 38 4,7 Vertical
AC 480V +10% 180 3 NFD
03.1-480-180
95 95 AWG 4/0 61 10 Vertical
DOK-INDRV*-HCS01******-PR05-EN-P Bosch Rexroth AG 295/341
Rexroth IndraDrive CsDrive Systems with HCS01
Cables, accessories, additional components
