C
Y_K typ
Capacitance per unit length of cables
C
ab_Kg
Total leakage capacitance of cables
Fig. 11-4: Total leakage capacitance of cables
The total capacitance C
_ab_Kg
consists of the sum of capacitances of the indi‐
vidual power cables. For the individual capacitances per unit length, see the
technical data of the power cables. For a list of selected values, see Appen‐
dix of this documentation under chapter 11.3 "Leakage Capacitances" on
page 326.
11.3 Leakage Capacitances
11.3.1 Leakage Capacitance of Motors
The data of the typical leakage capacitance refer to the total capacitance of
the power connections U, V, W against the motor housing. The tables below
contain excerpts from the technical data of motors:
Leakage capacitance
Type Leakage capacitance of the component
C
ab
nF
MSM019A-0300-NN-__-___ 0,3
MSM019B-0300-NN-__-___ 0,7
MSM031B-0300-NN-__-___ 0,7
MSM031C-0300-NN-__-___ 1,4
MSM041B-0300-NN-__-___ 1,3
Last modification: 2008-11-20
Tab. 11-7: MSM019A-0300-NN, MSM019B-0300-NN
Type Leakage capacitance of the component
C
ab
nF
MSK030B-0900-NN-__-___-
____
0,7
MSK030C-0900-NN-__-___-
____
1,3
MSK040B-0450-NN-__-___-
____
1,3
MSK040C-0450-NN-__-___-
____
2,0
MSK043C-0600-NN-__-___-
____
2,1
Last modification: 2012-09-17
Bosch Rexroth AG DOK-INDRV*-HCS01******-PR05-EN-P326/341
Rexroth IndraDrive CsDrive Systems with HCS01
Appendix
