7.1.10 Analog Output
Data Unit min Typ. max
Output voltage V -10 +10
Output load, ohmic kΩ 2
Output load, capacitive nF 100
Resolution mV/incr 24
Conversion time (incl. response
time)
µs 750
250
1)
Output clock Position controller clock
Precision (in relation to the measur‐
ing range)
±0.5% with load ≥ 10 kΩ
±1% with load ≥ 2 kΩ
Short circuit protection Present
Overload protection Present
1) Applies to optional I/O extension DA
Tab. 7-38: Analog Output
